A06
Which product is right for you?
| Features | ||
| Common Features | ● ATSC3.0 / ATSC1.0 Tuner | |
| ● 4Kp60 AV1; 4Kp60 10-bit H.265; HDR；Dolby AC4 | ||
| ● System upgrading:Upgrade software via USB or network (OTA) | ||
| ● Built in ATSC3.0 App [AirTV] | ||
| ● Built in Youtube、NETFLIX、KODI | ||
| Basic parameters | ||
| System | SoC: Amlogic S905Y4-B | |
| CPU: ARM Quad 64-bit Cortex-A35 | ||
| GPU: ARM Mali-G31 MP2 | ||
| DRAM: LPDDR4 2GB | ||
| Flash: eMMC 8GB | ||
| OS: Android™11 | ||
| DRM:Widevine, Playready | ||
| Media | Video Decoder: AV1 MP-10 4K*2K@60fps,H.265 HEVC MP-10@L5.1 up to 4K*2K@60fps, VP9 Profile-2 up to4K*2K @60fps, AVS2-P2 up to 4K*2K@60fps, H.264 AVC HP up to 4K*2K@30fps,MPEG-4 ASP@L5 up to 1080P@60fps, MPEG-2 MP/HL up to 1080P@60fps, MPEG-1 MP/HL up to 1080P@60f, AVS+ JiZhun Profile up to 1080P@60fps |
|
| Video Format: MKV,MPG,MPEG,DAT. |
||
| Audio Decoder: MPEG1/2, MP3, AAC/HE-AAC,FLAC, OGG, DD，DD+，Dolby AC4/AC3 |
||
| Audio Format: MPEG1/2,MP3,AAC |
||
| Network | 2x2 MIMO Wi-Fi 2.4GHz/5 GHz 802.11 a/b/g/n/ac | |
| Connectivity | Video/Audio output:HDMI 2.0 (support CEC） | |
| Power Interface:USB-C 5V 2A | ||
| Other interface:Bluetooth Remote | ||
| Other | Input voltage:USB-C input 5V 2A | |
| Power consumption:10W Max | ||
| Operation temperature:0~40℃ | ||
| Material: Plastic & aluminium | ||
| Proposed Accessory:Bluetooth Remote, 5V2A Type C cable | ||
Package List
| Features | ||
| Common Features | ● ATSC3.0 / ATSC1.0 Tuner | |
| ● 4Kp60 AV1; 4Kp60 10-bit H.265; HDR；Dolby AC4 | ||
| ● System upgrading:Upgrade software via USB or network (OTA) | ||
| ● Built in ATSC3.0 App [AirTV] | ||
| ● Built in Youtube、NETFLIX、KODI | ||
| Basic parameters | ||
| System | SoC: Amlogic S905Y4-B | |
| CPU: ARM Quad 64-bit Cortex-A35 | ||
| GPU: ARM Mali-G31 MP2 | ||
| DRAM: LPDDR4 2GB | ||
| Flash: eMMC 8GB | ||
| OS: Android™11 | ||
| DRM:Widevine, Playready | ||
| Media | Video Decoder: AV1 MP-10 4K*2K@60fps,H.265 HEVC MP-10@L5.1 up to 4K*2K@60fps, VP9 Profile-2 up to4K*2K @60fps, AVS2-P2 up to 4K*2K@60fps, H.264 AVC HP up to 4K*2K@30fps,MPEG-4 ASP@L5 up to 1080P@60fps, MPEG-2 MP/HL up to 1080P@60fps, MPEG-1 MP/HL up to 1080P@60f, AVS+ JiZhun Profile up to 1080P@60fps |
|
| Video Format: MKV,MPG,MPEG,DAT. |
||
| Audio Decoder: MPEG1/2, MP3, AAC/HE-AAC,FLAC, OGG, DD，DD+，Dolby AC4/AC3 |
||
| Audio Format: MPEG1/2,MP3,AAC |
||
| Network | 2x2 MIMO Wi-Fi 2.4GHz/5 GHz 802.11 a/b/g/n/ac | |
| Connectivity | Video/Audio output:HDMI 2.0 (support CEC） | |
| Power Interface:USB-C 5V 2A | ||
| Other interface:Bluetooth Remote | ||
| Other | Input voltage:USB-C input 5V 2A | |
| Power consumption:10W Max | ||
| Operation temperature:0~40℃ | ||
| Material: Plastic & aluminium | ||
| Proposed Accessory:Bluetooth Remote, 5V2A Type C cable | ||
Optional
Optional
